Single-Phase AC200 V CIMR-VoBA0006F ~ 0018F
Three-Phase AC200 V CIMR-Vo2A0010F ~ 0020F
Three-Phase AC400 V CIMR-Vo4A0001F ~ 0011F
A
B
C
D
E
F
H
G
I
J
K
L
M
O
P
N
A –
Fan cover
<1>
B – Mounting hole
C – Heatsink
D – Optional 24 V DC power
supply connector cover
E – Terminal board Refer to
Control Circuit Terminal
Block Functions on page
66
F – Cover screws
G – Rubber bushing
H – Bottom cover
I – Front cover screws
J – Front cover
K – Terminal cover
L – Comm port
M – LED operator Refer to
Using the Digital LED
Operator on page 82
N – Case
O – Top cover
P –
Cooling fan
<1>
Figure 1.6 Exploded view of IP20/NEMA Type 1 Components
Three-Phase AC200 V CIMR-Vo2A0012F
<1> The drives CIMR-VoBA0006B and CIMR-Vo4A0001B ~ 0004B do not have a cooling fan
or a cooling fan cover. The drive CIMR-VoBA0018B has two cooling fans.
1.2 Component Names
YASKAWA ELECTRIC TOEP C710606 47A YASKAWA AC Drive – V1000 Quick Start Guide
35
1
Receiving
