No. Name Description
H4-03
Multi-Function Analog Output
Terminal AM Gain
Refer to V1000 Technical Manual for details.
H5: MEMOBUS/Modbus Communications
Use H5 Parameters to connect the drive to a MEMOBUS/Modbus network.
H5-01 Drive Node Address
Selects drive station node number (address) for MEMOBUS/Modbus
terminals R+, R-, S+, S-. Cycle power for the setting to take effect.
H5-02 Communication Speed Selection
0: 1200 bps
1: 2400 bps
2: 4800 bps
3: 9600 bps
4: 19200 bps
5: 38400 bps
6: 57600 bps
7: 76800 bps
8: 115200 bps
H5-03 Communication Parity Selection
0: No parity
1: Even parity
2: Odd parity
H5-04
Stopping Method After
Communication Error
0: Ramp to stop
1: Coast to stop
2: Fast-stop
3: Alarm only
H5-05
Communication Fault Detection
Selection
0: Disabled
1: Enabled - If communication is lost for more than two seconds, a CE
fault will occur.
H5-06 Drive Transmit Wait Time Set the wait time between receiving and sending data.
H5-07 RTS Control Selection
0: Disabled - RTS is always on.
1: Enabled - RTS turns on only when sending.
H5-09 CE Detection Time Refer to V1000 Technical Manual for details.
H5-10
Unit Selection for MEMOBUS/
Modbus Register 0025H
Refer to V1000 Technical Manual for details.
H5-11
Communications ENTER
Function Selection
Refer to V1000 Technical Manual for details.
H5-12 Run Command Method Selection Refer to V1000 Technical Manual for details.
H6: Pulse Train Input/Output
Use H6 parameters to configure Pulse Train I/O operation.
H6-01
Pulse Train Input Terminal RP
Function Selection
0: Frequency reference
1: PID feedback value
2: PID setpoint value
3: Simple PG V/f control mode (can be set only when using motor 1 in
the V/f control mode)
H6-02 Pulse Train Input Scaling
Sets the number of pulses (Hz) that is equal to 100% of the value
selected in H6-01.
H6-03 Pulse Train Input Gain
Sets the level of the value selected in H6-01 when a frequency with the
value set in H6-02 is input.
H6-04 Pulse Train Input Bias Sets the level of the value selected in H6-01 when 0 Hz is input.
