Single-Phase 200 V Class
Table 3.2 Wire Gauge and Torque Specifications
Model
CIMR-
VoBA
Terminal
Recomm.
Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening
Torque
N•m (lb.in.)
0001
0002
0003
R/L1, S/L2, T/L3 14 18 to 14
M3.5
0.8 to 1.0
(7.1 to 8.9)
U/T1, V/T2, W/T3 14 18 to 14
–, +1, +2 – 18 to 14
B1, B2 – 18 to 14
14 18 to 14
0006
R/L1, S/L2, T/L3 12 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
–, +1, +2 – 14 to 10
B1, B2 – 14 to 10
10 14 to 10
0010
R/L1, S/L2, T/L3 10 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
–, +1, +2 – 14 to 10
B1, B2 – 14 to 10
10 14 to 10
0012
R/L1, S/L2, T/L3 10 14 to 10
M4
2.3 to 2.5
(20.4 to 22.1)
U/T1, V/T2, W/T3 14 14 to 10
–, +1, +2 – 14 to 10
B1, B2 – 14 to 10
10 14 to 10
0018
R/L1, S/L2, T/L3 8 12 to 8
M5
2.3 to 2.5
(20.4 to 22.1)
U/T1, V/T2, W/T3 10 12 to 8
–, +1, +2 – 12 to 8
B1, B2 – 12 to 8
8 12 to 8
2 to 2.5
(17.7 to 22.1)
3.4 Main Circuit Wiring
