Yealink SIP-T38G Administrator's Guide

Resource Files
205
Procedure
Use the following procedures to customize an XML phonebook.
Customizing an XML phonebook:
1. Open the template file using an ASCII editor.
2. For each contact that you want to add, add the following strings to the IP
phonebook, each starting on a separate line:
<Name> Mary </Name>
<Telephone> 1001 </Telephone>
Where:
Specify the contact name between <Name> and </Name>.
Specify the contact number between <Telephone> and </Telephone>.
3. Specify the values within double quotes.
4. Place this file to the root directory of the provisioning server.
The following is an example of an XML phonebook:
<YealinkIPPhoneDirectory>
<DirectoryEntry>
<Name>Jack</Name>
<Telephone>1003</Telephone>
</DirectoryEntry>
<DirectoryEntry>
<Name>John</Name>
<Telephone>1004</Telephone>
</DirectoryEntry>
<DirectoryEntry>
<Name>Marry</Name>
<Telephone>1005</Telephone>
</DirectoryEntry>
</YealinkIPPhoneDirectory>
Access URL of the resource file can be configured in the configuration files:
Configuration File
<y0000000000xx>.cfg
Configure the access URL of the
replace rule template.
For more information, refer to
Access URL of Replace Rule

Yealink SIP-T38G Specifications

General

Expansion module support	Yes
Ethernet LAN (RJ-45) ports	2
Keypad number of keys	48
Touchscreen	-
Display resolution	480 x 272 pixels
Display number of colors	16.78 million colors
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723.1, G.726
Bluetooth	No
Security algorithms	802.1x RADIUS, HTTPS, SSL/TLS
AC adapter input voltage	100 - 240 V
AC adapter output voltage	5 V
Power consumption (typical)	4.6 W
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Compliance industry standards	IEEE 802.3af
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	204 mm
Width	273 mm
Height	42 mm
Weight	1050 g
