Yealink SIP-T38G Administrator's Guide

Administrator’s Guide for SIP-T3xG IP Phones
210
5. Click Export to open file download window, and then save the file to your local
system.
To capture packets using the Ethernet software:
Connect the IP phone’s Internet port with the PC to the same HUB, and then use Sniffer,
Ethereal or Wireshark software to capture the packets. You can also set a mirror port in
the switch to monitor the port of the connected IP phone.
The IP phone provides a troubleshooting feature called ―Watch Dog‖, which helps you
monitor the IP phone status and provides the ability to get stack traces from the last time
the IP phone failed. When the Watch Dog feature is enabled, the IP phone will
automatically reboot when it detects a fatal failure. This feature can be configured using
the configuration files or the web user interface.
You can use the ―watch_dog.enable‖ parameter to configure the Watch Dog feature in
the configuration files. For more information, refer to Watch Dog on page 317.
To configure the Watch Dog feature via web user interface:
1. Click on Phone->Preference.

Yealink SIP-T38G Specifications

General

Expansion module support	Yes
Ethernet LAN (RJ-45) ports	2
Keypad number of keys	48
Touchscreen	-
Display resolution	480 x 272 pixels
Display number of colors	16.78 million colors
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723.1, G.726
Bluetooth	No
Security algorithms	802.1x RADIUS, HTTPS, SSL/TLS
AC adapter input voltage	100 - 240 V
AC adapter output voltage	5 V
Power consumption (typical)	4.6 W
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Compliance industry standards	IEEE 802.3af
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	204 mm
Width	273 mm
Height	42 mm
Weight	1050 g
