YOKOGAWA FLXA402T User Manual

<3. Converter menu>
3-3
IM 12A01G01-03EN 1st Edition :Mar. 25, 2021-00
n Analog output
For setting mA output, go to
> Converter menu > “Setting” > “Converter settings” > “mA output settings” >
“mA1/2/3/4”
See 4.3 mA output settings for further information.
mA output in HOLD shows “HOLD.”
Alarms , , , indicate the device status in trouble related to analog output.
When mA input/output is “-A2”, mA3 and mA4 are displayed in gray “-------.”
n Contact output
Displays S1 to S4, “Contact output.”
For setting of contacts or parameters, go to
> Converter menu > “Setting” > “Converter settings” > “Contact output settings (R)” >
“S1/S2/S3/S4”
For further information, see 4.4 Contact output settings.
When the su󰀩x code includes "-NR" (Without Contact outputs), the contact output is not
displayed.
n Input value
Shows analog input (mA).
For mA input, go to
> Converter menu > “Setting” > “Converter settings” > “mA input settings (Ad)”
For further information see 4.1 mA input settings (Ad)
When mA input/output is “-A2”, AI is displayed in gray “-------.”
Contact input status is dened NC: Normal Close / NO: Normal Open.
For Contact input setting, go to
> Converter menu > “Setting” > “Converter setting” > Contact input settings
For details, see 4.2 Contact input settings
When mA input/output is "-A2", DI2 is displayed in gray “-------.”
n Product information 1
“Serial No.” Housing serial number,
Model Code Model and su󰀩x code
n Product information 2
Sensor serial number,
“Internal serial No.” (“Housing”, “Second sensor module”, “IO module”, “COM module
“Revision” “Ethernet” “Bluetooth Device Revision”.
Scroll the page with . If no information is available, "----" appears in the corresponding item.
