YOKOGAWA ScopeCorder DL850E User Manual

4-17
IM DL850E-01EN
Level for Detecting the Start and End Points (Level) and Detection Hysteresis
(Hysteresis)
If you set the sync channel to a channel from CH1 to CH16, you need to set the level for detecting the start
and end points and set the detection hysteresis. These items are the same as the trigger level
and
hysteresis
of the simple trigger.
Trigger Hold-Off (Hold Off), Trigger Position (Position), Trigger Delay (Delay)
These items are the same as trigger hold-off , trigger position , and trigger delay
of the simple trigger.
Operating Conditions of the Wave Window Trigger
You can use the wave window trigger with the following waveforms and settings. You cannot use the wave
window trigger when the record length is 25 kpoint or less and the time axis setting is shorter than 10 ms/div.
Waveforms AC waveforms and triangular waveforms between 40 kHz and 1 kHz.
(The trigger cannot be used with rectangular waveforms, such as
inverter waveforms, or waveforms with fast rising edges.)
Sample rate 10 kS/s to 500 kS/s
Acquisition mode Normal
Trigger mode Normal, Single, Single(N)
When the trigger mode is Auto or Auto Level, it is difficult for the wave
window trigger to occur.
Dual capture feature OFF
4 Triggering
