YOKOGAWA ScopeCorder DL850E User Manual

11-7
IM DL850E-01EN
Averaging Settings (Average Setup) - user-defined
You can average and compute the peak values of the results of user-defined computation.
Averaging Modes (Average Mode)
The following types of averaging are available.
• OFF: Averaging is not performed.
•
Linear averaging (Linear)
: Values are averaged linearly.
• Exponential averaging (Exp): Values are averaged exponentially.
•
Cycle averaging (Cycle): Values are averaged across cycles.
• Peak computation (Peak
): Peak values are computed.
Linear Averaging (Linear)
The number of values specified by the average count are added and divided by the average count, and the
resulting values are used to display the waveform. For the equation, see the equation for linear averaging in
A
veraging Mode.
•
Average Domain (Average Domain)
Select what to average.
• Time:
A time-domain waveform is averaged.
• Freq:
A frequency-domain waveform is averaged.
• Linear Count (Linear Count)
Set the average count.
Selectable range: 2 to 128 in 2
n
steps
Exponential Averaging (Exp)
Using the specified attenuation constant, the DL850E/DL850EV attenuates the influence of previous computed
data to produce averaged values, and uses the results to display the waveform. For the equation, see the
equation for exponential averaging in Averaging Mode.
•
Average Domain (Average Domain)
• Attenuation Constant (Average Weight)
Set the attenuation constant.
Selectable range: 2 to 256 in 2
n
steps
11 Computation
