YOKOGAWA ScopeCorder DL850E User Manual

11-1
IM DL850E-01EN
11 Computation
You can perform various computations on up to 1 Mpoint of data. (When more than 1 Mpoint of waveform data is
displayed, computation is performed on the first 1 Mpoint of data from the computation start point.)
The results of computation are displayed in Math1 to Math8. Waveforms stored through hard disk recording
cannot be computed.
Turning Computation On and Off (Mode)
Select whether to use computation.
• ON: Computation is used.
• OFF: Computation is not used.
Digital Filter and Real Time Math (Optional)
Computation Waveform Selection (Select Math Trace)
Select a computed waveform to use to display the computation results.
Math1 to Math8
Computation Settings (Math Setup)
Operators and Functions (Operation)
Select an operator or function (operation definition) from the options below.
• OFF: Computation is not performed.
•
S1+S2: Adds the waveforms assigned to Source1 and Source2
• S1−S2: Subtracts the waveform assigned to Source2 from the waveform assigned to Source1
• S1*S
2: Multiplies the waveforms assigned to Source1 and Source2
• S1/S2: Divides the waveform assigned to Source1 by waveform assigned to Source2
•
Bin(S1): Converts the waveform assigned to Source to binary
• PS(S1): Computes the power spectrum of the waveform assigned to Source
• Shift(S1): Shows the waveform assigned to Source with its phase shifted
• User Define
: Performs user-defined computation (/G2 option).
