YOKOGAWA ScopeCorder DL850E User Manual

2-51
IM DL850E-01EN
Displaying the Menu for Configuring All Channels (ALL CH)
Input Settings (Setup)
You can configure the settings of all channels while viewing the settings in a list. You can also copy the various
vertical axis settings of one channel to another channel. There are some items that cannot be configured from
the ALL CH menu.
Measurement Type Settings
Voltage Waveform display color, waveform display (Disp), label (Label), coupling (Coupling), vertical
scale (V Scale), bandwidth limit (Band Width), zoom method (DIV/Scale), offset (Offset), position
(Position), magnification for zooming (V Zoom), display range limits for zooming (Upper/Lower),
probe attenuation and current-to-voltage conversion ratio (Probe)
Voltage (for the
16-CH voltage input
module)
Waveform display color, waveform display (Disp), label (Label), coupling (Coupling), vertical
scale (V Scale), bandwidth limit (Band Width), zoom method (DIV/Scale), offset (Offset), position
(Position), magnification for zooming (V Zoom), display range limits for zooming (Upper/Lower)
Temperature Waveform display color, waveform display (Disp), label (Label), coupling (Coupling),
thermocouple type (Type), bandwidth limit (Band Width), display range settings (Upper/Lower),
reference junction compensation (RJC), burnout (Burn Out)
Temperature (for the
16-CH temperature/
voltage input module)
Waveform display color, waveform display (Disp), label (Label), coupling (Coupling),
thermocouple type (Type), bandwidth limit (Band Width), display range settings (Upper/Lower),
reference junction compensation (RJC), burnout (Burn Out), vertical scale (V Scale), zoom
method (DIV/Scale), offset (Offset), position (Position), magnification for zooming (V Zoom),
display range limits for zooming (Upper/Lower)
Strain Waveform display color, waveform display (Disp), label (Label), range unit (Range Unit),
measurement range (Range), bandwidth limit (Band Width), display range settings (Upper/
Lower), gauge factor (Gauge Factor), bridge voltage (Excitation)
Acceleration Waveform display color, waveform display (Disp), label (Label), coupling (Coupling), gain (Gain),
bandwidth limit (Band Width), zoom method (DIV/Scale), position (Position), magnification for
zooming (V Zoom), display range limits for zooming (Upper/Lower), sensitivity (Sensitivity)
Frequency Waveform display color, waveform display (Disp), label (Label), measured item (Function),
vertical scale (V Scale), zoom method (DIV/Scale), offset (Offset), position (Position),
magnification for zooming (V Zoom), display range limits for zooming (Upper/Lower), center
frequency (CenterFreq), input settings (Input)
Logic Waveform display color, waveform display (Disp), label (Label), bit display (Bit Display),
chattering elimination (Chatter Elim.), position (Position), magnification for zooming (V Zoom), bit
mapping (Mapping)
* In the setup menu for configuring all channels, for channels that correspond to CAN bus monitor modules
or CAN & LIN bus monitor modules, you can set only the Display setting, which determines whether
waveforms are displayed.
2 Vertical Axis
