9-5
IM DL850E-01EN
Markers (Marker1 through 4)
Select the markers, from Marker1 to 4, that you want to display. You can assign each marker to a different
waveform.
Measurement Source Waveform (Trace)
Set the measurement source waveform to one of the waveforms below.
•
OFF: Disables the marker
• CH1 to CH16,
1
16chVOLT,
2
16chTEMP/VOLT,
2
CAN,
3
LIN,
3
Math1 to Math8
1 You can select the channel of an installed module. However, you cannot select the channel of a logic module.
2 When a 16-CH voltage input module or 16-CH temperature/voltage input module is installed. After you select
16chVOLT or 16chTEMP/VOLT, select a sub channel.
3 On the DL850EV when a CAN bus monitor module or CAN & LIN bus monitor module is installed. After you
select CAN or LIN, select a sub channel. You cannot select waveforms whose data type (V
alue Type) is set to
Logic.
Position (Position)
Set the position of the selected marker.
Taking the center of the waveform display window to be 0 div, you can move the markers within the range of −5
to 5 div in steps of the following size: Time/div × 10 ÷ display record length.
Cursor Jumping (Cursor Jump)
You can make Marker1 to Marker4 jump to the center of the specified zoom window.
To Zoom1: The selected marker jumps to the Zoom1 window.
To Zoom2: The selected marker jumps to the Zoom2 window.
Marker Shape (Marker Form)
Set the shape of the displayed marker to one of the options below.
•
Mark: A dot
• Line: A
crosshair
Measurement Items (Display Item)
Marker cursors move on the waveform data. You can measure the following values at the markers.
X1 Time value at Marker1
X2 Time value at Marker2
X3 Time value at Marker3
X4 Time value at Marker4
Δ(X2-X1) Difference between the time values of Marker1 and Marker2
Δ(X3-X1) Difference between the time values of Marker1 and Marker3
Δ(X4-X1) Difference between the time values of Marker1 and Marker4
Δ(X3-X2) Difference between the time values of Marker2 and Marker3
Δ(X4-X2) Difference between the time values of Marker2 and Marker4
Δ(X4-X3) Difference between the time values of Marker3 and Marker4
Y1 Vertical value at Marker1
Y2 Vertical value at Marker2
Y3 Vertical value at Marker3
Y4 Vertical value at Marker4
Δ(Y2-Y1) Difference between the vertical values of Marker1 and Marker2
Δ(Y3-Y1) Difference between the vertical values of Marker1 and Marker3
Δ(Y4-Y1) Difference between the vertical values of Marker1 and Marker4
Δ(Y3-Y2) Difference between the vertical values of Marker2 and Marker3
Δ(Y4-Y2) Difference between the vertical values of Marker2 and Marker4
Δ(Y4-Y3) Difference between the vertical values of Marker3 and Marker4
9 Cursor Measurement
