Moving the Cursors (Cursor1/Cursor2)
Use Cursor1 and Cursor2 to move the cursors.
Taking the center of the waveform display window to be 0 div, you can move the cursors within the range of −5 to
5 div in 0.01 div steps.
Measurement Items (Item Setup)
You can measure the following horizontal (X axis) values at the cursor positions.
X1 Horizontal (X axis) value at Cursor1
X2 Horizontal (X axis) value at Cursor2
ΔX Difference between the horizontal (X axis) values of Cursor1 and Cursor2
Horizontal and Vertical Cursors (H & V)
You can display the horizontal and vertical cursors simultaneously and measure vertical (Y axis) and horizontal (X
axis) values.
Measurement Source Waveform (Trace)
Set the measurement source waveform to one of the waveforms below.
XY1 to XY8
Moving the Cursors (V Cursor1/V Cursor2, H Cursor1/H Cursor2)
Use V-Cursor1, V-Cursor2, H-Cursor1, and H-Cursor2 to move the cursors.
Taking the center of the waveform display window to be 0 div, you can move the cursors within the range of −5 to
5 div in 0.01 div steps.
Measurement Items (Item Setup)
You can measure the following horizontal (X axis) and vertical (Y axis) values at the cursor positions.
Horizontal Axis (X axis)
X1 Horizontal (X axis) value at V-Cursor1
X2 Horizontal (X axis) value at V-Cursor2
ΔX Difference between the horizontal (X axis) values of V-Cursor1 and V-Cursor2
Vertical Axis (Y axis)
Y1 Vertical (Y axis) value at H-Cursor1
Y2 Vertical (Y axis) value at H-Cursor2
ΔY Difference between the vertical (Y axis) values of H-Cursor1 and H-Cursor2
Marker Cursors (Marker)
Four markers are displayed on the selected waveform. You can measure the level at each marker, the amount of
time from the trigger position to each marker, and the level and time differences between markers.
Markers (Marker1 through 4)
Select the markers, from Marker1 to 4, that you want to display. You can assign each marker to a different
waveform.
Measurement Source Waveform (Trace)
Set the measurement source waveform to one of the waveforms below.
XY1 to XY8
9 Cursor Measurement
