13-3
IM DL850E-01EN
Action Condition (ActCondition)
Set the action condition to one of the settings below.
• Always (Always): The actions are always performed. The actions will be executed each time that the DL850E/
DL850EV triggers.
• At failure (Fail): The actions are executed when the specified G
O conditions are not met.
• At success (Success): The actions are executed when the spe
cified GO conditions are met.
Sequence (Sequence)
Select the sequence for executing actions.
•
Single (Single): Execution stops after the actions are performed once.
• Continue (Continue): Actions are executed repeatedly. However
, the actions stop repeating after the number
of specified waveform acquisitions (the Acquisition Count setting). If Acquisition Count is set to Infinite, the
actions continue until waveform acquisition is stopped by the pressing of the START/STOP key.
Acquisition Count (Acquisition Count)
Set the number of waveform acquisitions.
•
Infinite: Waveform acquisition continues until it is stopped by the pressing of the START/ST
OP key.
• 1 to 65536: The DL850E/DL850EV stops waveform acquisition after it acquires the specified number of
waveforms.
External Start (Ext Start)
You can perform GO/NO-GO determination and output the results in sync with an external signal applied to the
GO/NO-GO I/O terminal of the DL850E/DL850EV.
•
OFF: GO/NO-GO determination is not performed through the use of an external signal.
• ON: GO/NO-GO determination is performed through the use of an external signal.
Action (Action)
Determination Period (Time Range1 and Time Range2)
You can set the determination period by setting Time Range1 and Time Range2. The default settings are −5 div
and +5 div.
Selectable range: −5 div to +5 div
The determination period is similar to the settable range of the cursor display position in cursor measurement.
For details, see “Selectable Range of Cursor Positions.”
GO/NO-GO Determination Results
The results of GO/NO-GO determination (and the numbers of determinations and failures) appear at the bottom
of the screen.
Determination
count
Failure count
Exe Count: 10 Fail Count: 2 Result: XXOOOO------------
O: Condition met
X: Condition not met
- : No condition specified
Indication of whether reference
conditions 1 to 16 are met
XXOOOO------------
1,2,3, ...,16: Reference conditions
In this example, reference conditions 1 and 2 are not met while the conditions defined
by base waveforms 3 to 6 are met.
13 GO/NO-GO Determination
To Next Page
