• Single-Phase Two-wire (1P2W)

Two channels that receive one pair of voltage and current signals can be wired.

LOAD

SOURCE

CH1

CH2

LOADSOURCE

Clamp sensor

• Single-Phase Three-Wire (1P3W)

Four channels that receive two pairs of voltage and current signals can be wired.

SOURCE

LOAD

H L

CH1

CH2

CH3

CH4

SOURCE

Clamp sensor
