If the Calculation Period Is AC+DC
• Edge Detection Source (Edge Source)
The options are the same as Edge.
• Hysteresis (Hysteresis) and Edge Source Filter (Edge Source Filter)
The options are the same as Edge.
• Stop Prediction (Stop Prediction)
The options are the same as Edge.
• Update Time (Auto Timer)
Range: 100 ns to 500 ms. Resolution: 100 ns.
Vertical Scale (Value/Div) Optimization (ALL Output Optimize
Value/Div)
This is the same feature as Optimize Value/Div of real time math (RealTime Math).
Analysis Setting (Analysis Setting)
Set how to calculate power math values.
• RMS Type (RMS Type)
Select the rms value from the following.
True RMS (rms value), Rect.Mean(rectified mean value calibrated to the rms value)
• φ Scaling (φ Scale)
Select how to display phase differences.
Radian: Radian
Degree: Degrees
• Reset on Start (Reset Condition on Start)
OFF: Integration continues regardless of the START/STOP key state.
ON: Integration is performed only when the START/STOP key is set to start. The integrated value is reset to
zero when the key is set to stop.
• Scaling (Scaling)
Select the integral time unit.
Second: Second
Hour: Hour
Efficiency Setting (Efficiency Setting)
Select the measurement function efficiency η type from the following.
• Power
The power efficiency is calculated. Available when the analysis mode is 2Wirig System.
• Motor
The motor drive efficiency is calculated.
• OFF
Efficiency is not calculated.
