YOKOGAWA ScopeCorder DL850E User Manual

App-31
IM DL850E-01EN
Appendix
Label Item Description Number of
Parameters
Notes Data
Example
$Private
Info
A label indicating the
beginning of common
information
0
Format
Version
File format version
number
1
1.00
Model Measuring instrument
model
DL850E
Endian Waveform data
endianness
Big
Data
Format
Waveform data save
format (Trace or
Block)
Fixed to
Trace
Trace
Group
Number
Number of trace
groups
2
Trace
Total
Number
Number of traces 8
Data
Offset
Offset in waveform
data file
682874
$Group
1
Label indicating the
beginning of a group
(a number from 1
to GroupNumber is
attached to the end)
0
Trace
Number
Number of traces in
the group
1
4
Block
Number
Number of history
entries
5
Trace
Name
Trace name (label)
Trace
Number
(1 to 4)
Spaces are
converted to
underscores.
CH1
Block
Size
Number of data points 10010
V
Resolution
Y-axis conversion
coefficient
(VResolution × raw
data value + VOffset)
8.3333333E-04
VOffset Y-axis offset 0.0000000E+00
VData
Type
Binary data type
(integer or real
number, signed or
unsigned, number of
bytes per data)
IS2
VUnit Y-axis unit V
VPlus
OverData
Upper limit of normal
data
Fixed to “?”
for reserve
?
VMinus
OverData
Lower limit of normal
data
Fixed to “?”
for reserve
?
VIllegal
Data
Hidden code value “?” for
modules that
do not have
a hidden
code
-32768
VMax
Data
Maximum data value Maximum
value that
the data type
can take on
32767
VMin
Data
Minimum data value Minimum
value that
the data type
can take on
-32767
