Setting All Sub Channels (All SubChannels Setup)
Input Settings (Setup)
You can configure the settings of all sub channels while viewing the settings in a list. The settings that you can
view and configure are listed below. The settings vary depending on the input module.
•
When the Input Coupling Is Set to DC, GND, or OFF
Display color, label (Label), coupling (Coupling), vertical scale (V Scale), bandwidth limit (Band Width), zoom
method (DIV/SPAN), offset (Of
fset), position (Position), magnification for zooming (V Zoom), display range
limits for zooming (Upper/Lower)
•
When the Input Coupling Is Set to TC
Display color, label (Label), coupling (Coupling), thermocouple type (Type), temperature unit (Unit), display
range settings (Upper/Lower), reference junction compensation (RJC), burnout (Burn Out)
Linear Scaling (Linear Scale)
You can configure the linear scaling settings of all sub channels while viewing the settings in a list.
The settings
that you can view and configure are listed below. You cannot configure these settings when the input coupling is
set to TC.
Linear scaling (Linear Scale);
A and B for AX+B or P1:X, P1:Y, P2:X, and P2:Y for P1-P2; unit string (Unit);
display mode (Disp
Type); number of decimal places (Decim Num); unit prefix (Sub Unit)
Copy (Copy to)
You can copy the various vertical axis and linear scaling settings of one sub channel to another sub channel.
• Source sub channel (Source Sub Channel)
You can set the source sub channel to a channel from channel 1 to 16.
• Destination sub channel (DestinationSub Channel)
You can set the destination sub channels by using the followin
g options.
Select ALL ON to select all sub channels, select ALL OFF to unselect all sub channels, and select
individual sub channels by selecting numbers 1 to 16.
• Execute (Execute)
Select Execute to copy the settings.
The waveform display color and label settings are not copied.
