Input Coupling (Coupling)
You can set the input coupling to DC, TC, GND, or OFF. Sub channels whose coupling is set to OFF are not
measured or displayed.
The setup menu varies depending on the input coupling that you select.
When the Input Coupling Is Set to DC, GND, or OFF
• Zoom Method (V Scale), Zooming by Setting a Magnification (V Zoom), Zooming by Setting Upper and
Lower Display Limits (Upper/Lower)
• Offset (Offset)
• Trace Settings (Trace Setup)
• Inverted Waveform Display (Invert)
• Linear Scaling (Linear Scale)
When the Input Coupling Is Set to TC
• Thermocouple Type (Type)
• Display Range (Upper/Lower)
• Temperature Unit (Unit)
• Trace Settings (Trace Setup)
• Reference Junction Compensation and Burnout (Temperature Setup)
Built-in reference junction in scanner box.
Notes about Using the 16-CH Voltage Input Module (720220),
Notes about Using the 16-CH Temperature/Voltage Input Module (720221)
