YOKOGAWA ScopeCorder DL850E User Manual

2-30
IM DL850E-01EN
Zoom Method (V Scale), Zooming by Setting a Magnification (V Zoom), Zooming by
Setting Upper and Lower Display Limits (Upper/Lower)
Gain (Gain)
You can set the ratio of the output signal to the input signal to a value from 0.1 to 100.
The default setting is 1.
Trace Settings (Trace Setup)
Sensitivity (Sensitivity)
You can set the sensitivity of the acceleration sensor that you are using to a value between 0.10 mV/Unit and
2000.00 mV/Unit.
Unit (Unit)
Set the unit of acceleration to be displayed using up to four characters. The default setting is m/s
2
. Change the
unit as necessary.
2 Vertical Axis
