68
IM 01B08B02-01EN
List of Parameters
STC Setting Display 2 (STC2)
Parameter Name Setting and Display Range Unit
Factory Default Value
Display and Setting Conditions
for Controller Mode
User
Set-
tings
YS1500
(SINGLE)
YS1700
(PROG)
SINGLE
CAS
SELECT
PROG
PV2 Process variable 2 Equivalent to -6.3 to 106.3% in the engineering unit (Note 1) Engineering Unit Undefined N/A R R R
SV2 Setpoint value 2 Equivalent to -6.3 to 106.3% in the engineering unit (Note 1) Engineering Unit 0.0 N/A R/W R/W R/W
MV2 Manipulated output variable 2 (Note 2) -6.3 to 106.3 % -6.3 N/A R R R
STC STC mode selection
OFF: STC is not operating DISP: STC values displayed only
ON: STC is operating ATSTUP: STC automatic start-up (Note 3)
OFF N/A R/W R/W R/W
OD On-demand tuning start OFF, ON OFF N/A R/W R/W R/W
PB2 Proportional band 2 0.1 to 999.9 % 999.9 N/A R/W R/W R/W
TI2 Integral time 2 1 to 9999 s (second) 1000 N/A R/W R/W R/W
TD2 Derivative time 2 0 to 9999 (0: OFF) s (second) 0 N/A R/W R/W R/W
IP2 Process type 2
STATIC: Static process
DYNAM: Astatic process (with integral characteristics)
STATIC N/A R/W R/W R/W
TR2 Process response time 2 4 to 9999 s (second) 300 N/A R/W R/W R/W
NB2 Noise band 2 Equivalent to 0.0 to 20.0% in the engineering unit (Note 1) Engineering Unit 0.0 N/A R/W R/W R/W
OS2 Control target type 2
ZERO: Overshoot zero
MIN: Overshoot: Small (About 5%) Settling time: Short
MED: Overshoot: (About 10%) Rise time: Medium-fast
MAX: Overshoot: (About 15%) Rise time: Fast
MED N/A R/W R/W R/W
MI2 MV applied signal span 2 0.0 to 20.0 % 5.0 N/A R/W R/W R/W
PMX2 High limit setpoint of proportional band 2 2.0 to 999.9 % 999.9 N/A R/W R/W R/W
PMN2 Low limit setpoint of proportional band 2 2.0 to 999.9 % 2.0 N/A R/W R/W R/W
IMX2 High limit setpoint of integral time 2 1 to 9999 s (second) 9999 N/A R/W R/W R/W
IMN2 Low limit setpoint of integral time 2 1 to 9999 s (second) 1 N/A R/W R/W R/W
DMX2 High limit setpoint of derivative time 2 0 to 9999 s (second) 2000 N/A R/W R/W R/W
PA2 Calculated proportional band 2 2.0 to 999.9 % 999.9 N/A R R R
IA2 Calculated integral time 2 1 to 9999 s (second) 1000 N/A R R R
DA2 Calculated derivative time 2 0 to 9999 s (second) 0 N/A R R R
CR2 Presumed accuracy error 2 0.00 to 99.99 % 0.00 N/A R R R
RT2 Signal distribution ratio 2 0.000 to 9.999 1.000 N/A R R R
LM2 Equivalent dead time 2 0 to 9999 s (second) 0 N/A R R R
TM2 Equivalent lag time 2 0 to 9999 s (second) 0 N/A R R R
GM2 Equivalent process gain 2 0.000 to 9.999 0.000 N/A R R R
Note 1: The engineering units set with the Engineering parameters, SCH2, SCL2, and SCDP2.
Note 2: MV (Manipulated output variable) can be set only with the MV operation key at the bottom of the front panel. MV will be displayed when the controller mode is set to cascade or selector.
Note 3: ATSTUP can not be set if the controller mode is set to the selector mode or the selector control module is being used in the programmable mode.
