81
IM 01B08B02-01EN
List of Parameters
List of Parameters
DI/DO Configuration Display 2/2 (DI/DO 2/2)
Parameter Name Setting and Display Range Unit
Factory
Default
Value
Display and Setting Conditions
for Controller Mode
User
Set-
tings
YS1500
(SINGLE)
SINGLE CAS
SELECT
PROG
SET Enable/Disable setting INHB: Setting impossible ENBL: Setting possible (Note1) INHB R/W R/W R/W N/A
DO1F DO1 function selection (Note 2)
NONE: OFF, PH1: High limit alarm for PV1, PL1: Low limit alarm for PV1,
HH1: High-high limit alarm for PV1, LL1: Low-low limit alarm for PV1,
DL1: Alarm for deviation variable 1, VL1: Velocity alarm for PV1,
PH2: High limit alarm for PV2, PL2: Low limit alarm for PV2,
HH2: High-high limit alarm for PV2, LL2: Low-low limit alarm for PV2,
DL2: Alarm for deviation variable 2, VL2: Velocity alarm for PV2,
DL1 VL1: Alarm for deviation variable 1/ Velocity alarm for PV1,
DL2 VL2: Alarm for deviation variable 2/ Velocity alarm for PV2,
1-ALM: OR for all alarms of the loop 1, 2-ALM: OR for all alarms of the loop 2
CAS: Cascade mode, CASAUT: Cascade or Automatic mode, O/C: Open/Close, L/R: Local/
Remote, OOP: Current output open
PH1 R/W R/W R/W N/A
DO2F DO2 function selection (Note 2) PL1 R/W R/W R/W N/A
DO3F DO3 function selection (Note 2) VL1 R/W R/W R/W N/A
DO4F DO4 function selection (Note 2) CAS R/W R/W R/W N/A
DO5F DO5 function selection (Note 2) CASAUT R/W R/W R/W N/A
DO6F DO6 function selection (Note 2) NONE R/W R/W R/W N/A
DO7F DO7 function selection (Note 2) (Note 3) NONE R/W R/W R/W N/A
DO8F DO8 function selection (Note 2) (Note 3) NONE R/W R/W R/W N/A
DO9F DO9 function selection (Note 2) (Note 3) NONE R/W R/W R/W N/A
DO10F DO10 function selection (Note 2) (Note 3) NONE R/W R/W R/W N/A
DO1D DO1 contact type
OPN: When the event occurs, the contact is opened
CLS: When the event occurs, the contact is closed
OPN R/W R/W R/W N/A
DO2D DO2 contact type OPN R/W R/W R/W N/A
DO3D DO3 contact type
OPN
R/W R/W R/W N/A
DO4D DO4 contact type
CLS
R/W R/W R/W N/A
DO5D DO5 contact type
CLS
R/W R/W R/W N/A
DO6D DO6 contact type OPN R/W R/W R/W N/A
DO7D DO7 contact type (Note 3) R/W R/W R/W N/A
DO8D DO8 contact type (Note 3) R/W R/W R/W N/A
DO9D DO9 contact type (Note 3) R/W R/W R/W N/A
DO10D DO10 contact type (Note 3) R/W R/W R/W N/A
Note 1: When the SET parameter is set to “ENBL”, [STOP] will appear on the right of the display title, and the manipulated output and alarm output will be kept.
Note 2: Ex. When DInD (n=1 to 10) is OPN, and the DO function parameter is:
CASAUT: The contact is open when in the cascade or automatic mode
O/C: The contact is closed when the internal cascade is in close status, the contact is open when the internal cascade is in open status.
L/R: The contact is closed when SV2 is local setpoint value, the contact is open when SV2 is cascade setpoint value.
All alarm related parameters: the contact is open when the alarm occurs.
Note 3: This value is displayed only on YS1700 Basic type with expandable I/O.
