Zebra TC20 User Manual

Application Deployment
133
ADB driver for Windows and Linux are available on the Zebra Support Central web site at
www.zebra.com/support
. Download the ADB and USB Driver Setup package. Follow the instructions with the
package to install the ADB and USB drivers for Windows and Linux.
Enabling USB Debugging
By default, USB debugging is disabled. To enable USB debugging:
1. Swipe down from the Status bar to open the Quick Access panel, and then touch .
2. Touch System > About phone.
3. Scroll down to Build number.
4. Tap Build number seven times. The message You are now a developer! appears.
5. Touch .
6. Touch Developer options.
7. Slide the USB debugging switch to the ON position.
8. Touch OK.
9. Connect the device to the host computer using the Rugged Charge/USB Cable.
The Allow USB debugging? dialog box appears on the device.
10.On the device, touch OK.
11.On the host computer, navigate to the
platform-tools folder.
12.Type
adb devices.
The following displays:
List of devices attached
XXXXXXXXXXXXXXX device
(where XXXXXXXXXXXXXXX is the device number).
NOTE: If device number does not appear, ensure that ADB drivers are installed properly.
13.Touch .
Application Installation
After an application is developed, install the application onto the device using one of the following methods:
• USB connection, see Installing Applications Using the USB Connection.
• Android Debug Bridge, see Installing Applications Using the Android Debug Bridge.
• microSD Card, see Installing Applications Using a microSD Card.
• Mobile device management (MDM) platforms that have application provisioning. Refer to the MDM software
documentation for details.
Installing Applications Using the USB Connection
CAUTION: When connecting the device to a host computer and mounting the microSD card, follow the host computer’s in-
structions for connecting and disconnecting USB devices, to avoid damaging or corrupting files.

Zebra TC20 Specifications

General

Display Size	4.3 inches
RAM	2 GB
Storage	16 GB
Battery Capacity	3000 mAh
Rear Camera	8 MP
Operating Temperature	-10°C to 50°C
IP Rating	IP54
Resolution	480 x 800 pixels
Operating System	Android
Connectivity	USB, Bluetooth, Wi-Fi
Weight	195 g
Touch Panel	Capacitive
Expansion Slot	microSD
Data Capture	1D/2D Barcode Scanner
Dimensions	134 mm x 73.1 mm x 16 mm
Wireless Connectivity	802.11 a/b/g/n/ac, Bluetooth 4.1
Front Camera	No
Durability	1.2 m drop to concrete
