Zebra TC20

Accessories
26
Setup
Figure 14 1-Slot Base Charge Only Cradle Setup
Cable Routing
To cradle provides three ways to route the USB cable:
• Rear
• Left side
• Right side.
Figure 15 USB Cable Routing
Insert the USB-C cable connector into the USB port. Routing the cable to the rear, left, or right and use cable
holders to secure cable.
Power Supply
USB-C Cable
USB C Port
Cable Holder
Cable Holder
