Accessories
38
5-Slot Charge Only Cradl
e
The 5-Slot Charge Only Cradle:
•
Provides 5 VDC power for operating the TC20.
•
Simultaneously charges up to five TC20s.
Figure 33 5-Slot Charge Only Cradle Setup
Charging the TC20
To charge a device:
1.
Insert the TC20 into a slot to begin chargin
g.
AC Line Cord
DC Line Cord
Power Supply
37
39
