DataWedge

• Linear Security Level - Sets the number of times a barcode is read to confirm an accurate decode.

• Security Short or Codabar - Two times read redundancy if short barcode or Codabar (default).

• Security All Twice - Two times read redundancy for all barcodes.

• Security Long and Short - Two times read redundancy for long barcodes, three times for short

barcodes.

• Security All Thrice - Three times read redundancy for all barcodes.

• HW Engine Low Power Timeout - Time (0 - 1,000 ms in increments of 50 ms) of inactivity before scanner

enters low-power mode from (default - 250).

• Picklist - Allows the imager to decode only the barcode that is directly under the cross-hair/reticle (+) part

of the pattern. This feature is useful in applications where multiple barcodes may appear in the field of view

during a decode session and only one of them is targeted for decode.

• Disabled – Disables Picklist mode. Any barcode within the field of view can be decoded (default).

• Enabled – Enables Picklist mode so that only the barcode under the projected reticle can be decoded.

• Poor Quality Decode Effort - Enable poor quality barcode decoding enhancement feature.

• Same Symbol Timeout - Controls the time the scanner is inactive between decoding same symbols.

Programmable in 500 msec increments from 0 to 5 seconds. The default is 500 msec.

• Scanning Modes - Scanning options available on the device.

• Single - Set to scan general barcodes (default).

• UDI - Set to scan healthcare specific barcodes.

• MultiBarcode - Set to scan multiple barcodes. When this option is selected, the Multibarcode params

can be set to read from 2 to 10 barcodes on a single scan.

Scan Params

Allows the configuration of Code ID and decode feedback options.

NOTE: Not all parameter options are available with all scanners. See the DataWedge app on each device for the available

scanners and parameter options.

• Code ID Type - A Code ID character identifies the code type of a scanned barcode. This is useful when the

reader is decoding more than one code type. Select a code ID character to insert between the prefix and

the decoded symbol.

• Code ID Type None - No prefix (default)

• Code ID Type AIM - Insert AIM Character prefix.

• Code ID Type Symbol - Insert Symbol character prefix.

• Engine Decode LED - Use to turn on scanner red LED when the scan beam is emitting either by scanner

trigger or using soft scan button.

• BT Disconnect On Exit - Bluetooth connection is disconnected when data capture application is closed .

• Connection Idle Time - Set connection idle time. The Bluetooth connection disconnects after being idle for

set time.

• Display BT Address Barcode - Enable or disable displaying Bluetooth Address bar code if there is no

Bluetooth scanner being paired when application tries to enable the Bluetooth scanner.

• Establish Connection Time - The timeout which the device will try to enable or reconnect to the Bluetooth

scanner when the Bluetooth scanner is not in the vicinity or not paired.

Zebra TC20 User Manual
