Accessories
41
Figure 37 Align Cradle on Studs
8. Secure cradle to top tray with two M2.5 safety screws.
Figure 38 Secure Cradle
9. Slide top tray onto bottom tray.
Figure 39 Slide Top Tray onto Bottom Tray
Safety Screws(2)
