Zebra TC70x User Manual

A - 2 TC75x User Guide for Android Version 6.0.1
Operating System Android 6.0 Marshmallow
Memory 2 GB RAM/16 GB Flash
Output Power USB - 5 VDC @ 500 mA max
User Environment
Operating Temperature -20°C to 50°C (-4°F to 122°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Charging Temperature 0° C to 40° C (32°F to 104°F)
Humidity 5 to 95% non-condensing
Drop Specification 8 ft./2.4 m to concrete at room temperature; 6 ft./1.8 m over the operating
temperature range
Tumble 2,000 3.2 ft./1.0 m tumbles; meets and exceeds IEC tumble specifications
Electrostatic Discharge (ESD) +/-15kVdc air discharge, +/-8kVdc direct discharge, +/-8kVdc indirect discharge
Sealing IP67 per applicable IEC sealing specifications
Vibration 4 g’s PK Sine (5 Hz to 2 kHz); 0.04g2/Hz Random (20 Hz to 2 kHz); 60 minute
duration per axis, 3 axis
Thermal Shock -40° C to 70° C (-40° F to 158° F) rapid transition
Interactive Sensor Technology (IST)
Motion Sensor 3-axis accelerometer provides motion-sensing for dynamic screen orientation
and power management
Light Sensor Ambient light sensor to auto adjust display backlight brightness
Wireless WAN Data and Voice Communications (TC75x only)
Frequency band Worldwide:
LTE: 700,800/850/900/1800/2100/2600 (FDD 28,20,5,8,3,1,7);
UMTS/HSPA/HSPA+: 850/900/1900/2100;
GSM/GPRS/EDGE: 850/900/1800/1900
Americas:
LTE: 700/850/1900/AWS/2100, (FDD 13,12,17,5,26,2,25,4,1);
UMTS/HSPA/HSPA+: 850, 900, AWS, 1900, 2100
GSM/GPRS/EDGE: 850/900/1800/1900;
CDMA: 850,1900 (BC0, BC10, BC1)
GPS Integrated, Autonomous, Assisted GPS (A-GPS), Navstar, GLONASS, Beidou,
Galileo
Wireless LAN Data and Voice Communications
Radio
2x2 MIMO; IEEE
®
802.11a/b/g/n/ac/d/h/i/r
Table A-1 TC70x/TC75x Technical Specifications (Continued)
Item Description

Zebra TC70x Specifications

General

Flash memory	32 GB
Internal memory	4 GB
Internal memory type	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Display diagonal	4.7 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 85 %
Battery voltage	3.7 V
Battery capacity	4620 mAh
Number of cores	6
Processor model	650
Processor family	Snapdragon
Processor frequency	1.8 GHz
Processor manufacturer	Qualcomm
Operating system installed	Android
Product color	Black
Linear (1D) barcodes supported	Code 39
International Protection (IP) code	IP67
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
Rear camera resolution (numeric)	13 MP
Speakers	Mono

Weight and Dimensions

Depth	28 mm
Width	84 mm
Height	161 mm
Weight	376 g
