Zebra TC70x User Manual

Technical Specifications A - 3
Data Rates Supported 5GHz: 802.11a/n/c - up to 866.7 Mbps
2.4GHz: 802.11b/g/n - up to 144 Mbps
Operating Channels Chan 1 - 13 (2412 - 2472 MHz), Chan 36 - 165 (5180 - 5825 MHz)
Channel Bandwidth: 20, 40, 80 MHz
Actual operating channels/frequencies depend on regulatory rules and
certification agency
Security WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP, and AES); WPA/WPA2
Enterprise (TKIP and AES) - EAP-TTLS (PAP, MSCHAP, MSCHAPv2),
EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC and LEAP
Wireless PAN Data and Voice Communications
Bluetooth Bluetooth v4.1 Low Energy
Data Capture Specifications
2D Imager SE4750-SR – 1D and 2D bar codes.
Camera
Rear: 13 Mega pixel auto focus with flash
Front: 1.3 Mega pixel fixed focus
Near Field Communications
(NFC)
ISO 14443 Type A ad B, FeliCa, and ISO 15963 cards. P2P mode and Card
Emulation via UICC and Host.
Communication and Messaging
Workforce Connect PTT Express (included) provides instant push-to-talk (PTT) small group communications across
Wi-Fi networks. Workforce Connect PTT Pro (supported) provides a scalable network agnostic push-to-talk solution
which also includes messaging, location services and two-way radio integration. Workforce Connect Voice client
(supported) enables the TC75x to function as a full featured mobile telephone with multi-line capability across Wi-Fi
networks.
2D Imager Engine (SE4750-SR) Specifications
Field of View Horizontal - 48.0°
Vertical - 36.7°
Image Resolution 1280 horizontal X 960 vertical pixels
Roll 360°
Pitch Angle +/- 60° from normal
Skew Tolerance +/- 60° from normal
Ambient Light Sunlight: 10,000 ft. candles (107,639 lux)
Table A-1 TC70x/TC75x Technical Specifications (Continued)
Item Description

Zebra TC70x Specifications

General

Flash memory	32 GB
Internal memory	4 GB
Internal memory type	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Display diagonal	4.7 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 85 %
Battery voltage	3.7 V
Battery capacity	4620 mAh
Number of cores	6
Processor model	650
Processor family	Snapdragon
Processor frequency	1.8 GHz
Processor manufacturer	Qualcomm
Operating system installed	Android
Product color	Black
Linear (1D) barcodes supported	Code 39
International Protection (IP) code	IP67
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
Rear camera resolution (numeric)	13 MP
Speakers	Mono

Weight and Dimensions

Depth	28 mm
Width	84 mm
Height	161 mm
Weight	376 g
