DataWedge
109
5. Touch String position option to specify the position of the string specified in the String to check for
option. The ADF rule is only applied if the specific string in String to check for is found at the specified
String position location (zero for the start of the string).
6. Touch the + or - to change the value.
7. Touch OK.
8. Touch String length option to specify a length for the received data. The ADF rule only applies to the
barcode data with that specified length.
9. Touch the + or - to change the value.
10.Touch OK.
11.Touch Source criteria option to associate an input device to an ADF rule. The ADF rule only applies to
data received from associated input devices.
12.Touch Barcode input. Options vary depending upon the device configuration.
13.Touch the Source enabled checkbox to accept data from this source.
Figure 22 Barcode Input Screen
14.For general barcode inputs, touch the All decoders enabled checkbox to select all bar code symbologies.
Deselect the All decoders enabled checkbox to individually select the symbologies.
15.Touch until the Rule screen appears.
16.If required, repeat steps to create another rule.
17.Touch until the Rule screen appears.
Defining an Action
NOTE: By default the Send remaining action is in the Actions list.
