Zebra TC8300 - Applications

Accessories
48
Figure 34 Install Feet
2. Secure plate to feet with four screws and four washers.
Mounting Cradle
To mount the cradle:
1. Align mounting slots on bottom of cradle with studs on plate.
Figure 35 Install Cradle onto Desk Mount
2. Secure cradle to plate using safety screw.
Screws (4)
Plate
Feet (2)
Studs (3)
