Getting Started
18
Setup
Perform these procedures to start using the TC8300 for the first time.
1. Install a micro secure digital (SD) card (optional).
2. Install the battery.
3. Charge the TC8300.
4. Power on the TC8300.
Installing the microSD Card
The microSD card slot provides secondary non-volatile storage. The slot is located under the back bezel of the
unit. Refer to the documentation provided with the card for more information, and follow the manufacturer's
recommendations for use.
WARNING: Follow proper electrostatic discharge (ESD) precautions to avoid damaging the microSD card. Proper ESD
precautions include, but are not limited to, working on an ESD mat and ensuring that the operator is properly grounded.
Remove back bezel only in a dry location.
NOTE: The Condensation Resistant configuration has six screws securing the back bezel.
When installing a microSD card on Condensation Resistant configurations, replace the Back Bezel with desiccant pack. See
Condensation Resistant Rear Bezel Replacement on page 68. Once the Rear Bezel is removed, the desiccant pack
absorbs ambient moisture and can lessen the life of the desiccant pack.
1. Remove the Torx T8 screws holding the back bezel in place.
5 Trigger Initiates data capture (programmable).
6 Push-To-Talk (PTT)
Button
Initiates Push-To-Talk communication (programmable).
7 Battery Pack Provides power to the device.
8 Hand Strap Mounting
Point
Use for installing the optional hand strap.
9 Proximity Sensor Long range proximity sensor (optional).
Table 2 Back View Descriptions (Continued)
Number Item Function
