Accessories
44
Figure 30 Insert Device into Cradle
2. Ensure the device is seated properly.
Battery Charging
Main Battery Charging
The device’s Charging/Notification LED indicates the status of the battery charging in the device. The 6,700
mAh battery charges from 0 - 90% in less than four hours at room temperature. The 7,000 mAh battery
charges from 0 - 90% in less than five hours at room temperature.
Spare Battery Charging
The Spare battery Charging LED on the cup indicates the status of the spare battery charging. The 6,700 mAh
battery charges from 0 - 90% in less than four hours at room temperature. The 7,000 mAh battery charges
from 0 - 90% in less than five hours at room temperature.
Charging Temperature
Charge batteries in temperatures from 0 °C to 40 °C (32 °F to 104 °F). The device or cradle always performs
battery charging in a safe and intelligent manner. At higher temperatures (e.g. approximately +37 °C (+98 °F))
the device or cradle may for small periods of time alternately enable and disable battery charging to keep the
Table 8 Spare Battery Charging LED Indicators
State Indication
Off The battery is not charging. The battery is not inserted correctly in the cradle or
connected to a power source. Cradle is not powered.
Solid Amber Healthy battery is charging.
Solid Green Healthy battery charging is complete.
Fast Blinking Red
(2 blinks/second)
Charging error, e.g.:
- Temperature is too low or too high.
- Charging has gone on too long without completion (typically eight hours).
Solid Red Unhealthy battery is charging or fully charged.
