Zebra TC8300 Integrator Guide

Accessories
41
6. Touch Disconnect.
7. Touch Eth0.
8. Touch and hold the IP Settings drop-down list and select Static.
Figure 27 Static IP Settings
9. In the IP address field, enter the proxy server address.
10.If required, in the Gateway text box, enter a gateway address for the device.
11.If required, in the Netmask field, enter the network mask address.
12.If required, in the DNS address fields, enter a Domain Name System (DNS) address.
13.Touch Connect.
14.Touch .
LED Indicators
There are two green LEDs on the side of the cradle and on each Ethernet port. These green LEDs light and
blink to indicate the data transfer rate.
Table 7 LED Data Rate Indicators
Data Rate 1000 LED 100/10 LED
1 Gbps On/Blink Off
100 Mbps Off On/Blink
10 Mbps Off On/Blink

Zebra TC8300 Specifications

General

Display diagonal	4 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	800 x 480 pixels
Display number of colors	16.78 million colors
USB 2.0 ports quantity	1
Flash memory	128 GB
Internal memory	8 GB
Internal memory type	-
Compatible memory cards	SDXC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Number of cores	2
Processor family	A110
Processor frequency	1.7 GHz
Battery capacity	6700 mAh
Operating system version	5.1
Operating system installed	Android
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Product color	Black
Phone function	No
International Protection (IP) code	IP65
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	64 mm
Width	76 mm
Height	233 mm
Weight	- g
