Accessories
60
Figure 55 Connect Cables
11.Secure top tray to bottom tray with four M5 screws (two on each side).
Figure 56 Secure Top Tray to Bottom Tray
See Rack Mount Installation on page 60 for installing the bracket onto a rack.
Rack Mount Installation
