Zebra TC8300 - 5-Slot Desktop Bracket; Assembly

Accessories
49
Figure 36 Install Safety Screw
5-Slot Desktop Bracket
Use the 5-Slot Desk Mount to mount the 5-Slot Charge Only cradles or the 5-Slot Ethernet cradles in a vertical
position.
Figure 37 5-Slot Desk Mount
Assembly
To assemble the 5-Slot Desk Mount:
1. Align plate mounting holes with holes in feet.
Safety Screw
