Zebra TC8300 Integrator Guide

Settings
145
Initiating the Main Chat Head
To initiate the Main Chat Head:
1. Open RxLogger.
2. Touch > Toggle Chat Head. The Main Chat Head icon appears on the screen.
3. Touch and drag the Main Chat head icon to move it around the screen.
Removing the Main Chat Head
To remove the Main Chat Head icon:
1. Touch and drag the icon. A circle with an X appears.
2. Move the icon over the circle and then release.
Viewing Logs
To view logs:
1. Touch the Main Chat Head icon. The Overlay View screen appears.
Figure 12 Overlay View Screen
2. Touch a log to open it. The user can open many logs with each displaying a new sub Chat Head.
3. If necessary, scroll left or right to view additional Sub Chat Head icons.

Zebra TC8300 Specifications

General

Display diagonal	4 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	800 x 480 pixels
Display number of colors	16.78 million colors
USB 2.0 ports quantity	1
Flash memory	128 GB
Internal memory	8 GB
Internal memory type	-
Compatible memory cards	SDXC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Number of cores	2
Processor family	A110
Processor frequency	1.7 GHz
Battery capacity	6700 mAh
Operating system version	5.1
Operating system installed	Android
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Product color	Black
Phone function	No
International Protection (IP) code	IP65
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	64 mm
Width	76 mm
Height	233 mm
Weight	- g
