Zebra TC8300 Integrator Guide

DataWedge
113
28.Change value to 8 and then touch OK.
29.Press .
30.Touch .
31.Touch New action.
32.Select Send up to.
33.Touch Send up to rule.
34.Touch String.
35.In the Enter a string text box, enter X.
36.Touch OK.
37.Touch .
38.Touch .
39.Touch New action.
40.Select Send char.
41.Touch Send char rule.
42.Touch Character code.
43.In the Enter character code text box, enter 32.
44.Touch OK.
45.Touch .
Figure 23 ADF Sample Screen
46.Ensure that an application is open on the device and a text field is in focus (text cursor in text field).
47.Aim the exit window at the barcode.

Zebra TC8300 Specifications

General

Display diagonal	4 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	800 x 480 pixels
Display number of colors	16.78 million colors
USB 2.0 ports quantity	1
Flash memory	128 GB
Internal memory	8 GB
Internal memory type	-
Compatible memory cards	SDXC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Number of cores	2
Processor family	A110
Processor frequency	1.7 GHz
Battery capacity	6700 mAh
Operating system version	5.1
Operating system installed	Android
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Product color	Black
Phone function	No
International Protection (IP) code	IP65
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	64 mm
Width	76 mm
Height	233 mm
Weight	- g
