Zebra TC8300 Integrator Guide

Specifications
170
USB USB 2.0 Client for service and maintenance.
Data Capture
Laser Scanning SE965 1D standard range scan engine.
Imager SE4750-MR medium range next generation omnidirectional 1D/2D imaging
engine.
SE4850-ER extended range imager
Camera 13 MP Autofocus with flash, f/2.4 aperture (optional).
NFC Multi-Protocol NFC (optional).
Zebra Interactive Sensor Technology (IST)
Motion Sensor 3-axis accelerometer; 3-axis gyroscope (optional).
Light Sensor Automatically adjusts display backlight.
Proximity Sensor for auto hands-free scanning (optional).
Item Description
Physical and Environmental Characteristics
Dimensions (H x L x W) 233 mm x 76 mm x 64 mm
9.17 in. x 2.99 in. x 2.52 in.
Weight Base: 490 g (17.2 oz)
Package 1: 500 g (17.6 oz)
Display Color Transflective LCD, 4 in. diagonal, 480 x 800 pixels, 24 bits (16.7 million
pixels), 400 Nits.
Touch Panel Multi-Touch projected capacitive; fingertip (bare or gloved) input; conductive
stylus supported (sold separately)); Corning
®
Gorilla
®
Glass
Backlight Configurable LED backlight control
Battery PowerPrecision+ rechargeable 4.2 VDC 6,700 mAh Lithium-Ion battery.
PowerPrecision+ rechargeable 4.2 VDC 7,000 mAh Lithium-Ion battery.
Backup Power Hot Swap battery backup
Expansion Slot SDHC up to 32 GB (FAT32 format); SDXC compliant microSD up to 128 GB
(exFAT format).
Expansion Port USB, Serial for ISV developers (optional)
Notifications Audible tone plus multi-color LEDs and vibration
Voice and Audio Dual Speakers, Bluetooth wireless headset support
Performance Characteristics
CPU Qualcomm Snapdragon ™ 660 octa-core, 2.2 GHz
Operating System Android-based AOSP and GMS V8.1 (Oreo) with Mobility Extensions (Mx), for
true enterprise class operating system.
Table 4 Technical Specifications (Continued)
Item Description

Zebra TC8300 Specifications

General

Display diagonal	4 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	800 x 480 pixels
Display number of colors	16.78 million colors
USB 2.0 ports quantity	1
Flash memory	128 GB
Internal memory	8 GB
Internal memory type	-
Compatible memory cards	SDXC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Number of cores	2
Processor family	A110
Processor frequency	1.7 GHz
Battery capacity	6700 mAh
Operating system version	5.1
Operating system installed	Android
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Product color	Black
Phone function	No
International Protection (IP) code	IP65
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	64 mm
Width	76 mm
Height	233 mm
Weight	- g
