Accessories
58
Figure 51 Power Supplies in Bottom Tray
7. Slide top tray onto bottom tray until top tray touches vertical power supply.
Figure 52 Slide top Tray onto Bottom Tray
8. Install 16 M2.5 studs onto top tray as shown below.
DC Y Cable 2
AC line Cord 2
Power Supply 1
Power Supply 2
AC line Cord 1
DC Y Cable 1
