Zebra ZE500 User Manual

107
Printer Configuration and Adjustment
Toggle Positioning
8/23/12 P1051584-002
6. Print additional labels at 2 in. (51 mm) per second by again running the PAUSE Self Test.
(Press and hold
PAUSE while turning on (I) the printer.)
7. Do both sides of the label print at the same level of gray?
If… Then…
Yes The toggles are positioned correctly. Increase the darkness setting to the
optimum level for the media being used.
No a. Readjust the position of the toggle or toggles toward the side that printed
lighter.
b. Print additional labels at 2 in. (51 mm) per second by again running the
PAUSE Self Test. (Press and hold
PAUSE while turning on (I) the printer.)
c. Repeat this step until both sides of the label print at the same level of gray.
d. Increase the darkness setting to the optimum level for the media being used.

Zebra ZE500 Specifications

General

Print technology	-
Maximum resolution	300 x 300 DPI
Maximum printing width	168 mm
Wi-Fi	No
Ethernet LAN	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Parallel ports quantity	1
Flash memory	64 MB
Internal memory	16 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 129-Auto, Code 39, Code 49, Code 93, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, MaxiCode, PDF417, POSTNET, QR Code, TLC39, UPC-A, UPC-E
Processor frequency	133 MHz
Page description languages	XML, ZPL, ZPL II
Display	LCD
Product color	Black
Housing material	Metal
Core diameter	25.4 mm
Ribbon length	600 m
Maximum label width	180 mm
Maximum media length	3810 mm
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 71 °C
Operating temperature (T-T)	32 - 104 °F
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 85 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	438 mm
Width	245 mm
Height	300 mm
Weight	17300 g
