Zebra ZE500 User Manual

Printer Configuration and Adjustment
Changing Printer Settings
82
P1051584-002 8/23/12
Maintenance and Diagnostic Tools
Table 7 • Maintenance and Diagnostic Tools
Early Warning
for Media and
Ribbon
When this feature is enabled, the print engine provides warnings when the media or
ribbon is reaching near the end of the roll.
Accepted values:
MEDIA DISABLED, MEDIA ENABLED
Related ZPL command(s):
^JH
SGD command used:
none
Control panel menu item: EARLY WARNING MEDIA on page 23
Printer web page:
View and Modify Printer Settings > General Setup
> Early Warning (Media)
Early Warning
for Maintenance
When this feature is enabled, the print engine provides warnings when the printhead
needs to be cleaned.
Accepted values:
MAINT. OFF, MAINT. ON
Related ZPL command(s):
^JH
SGD command used:
none
Control panel menu item: EARLY WARNING MAINTENANCE on page 25
Printer web page:
View and Modify Printer Settings > General Setup
> Early Warning (Maintenance)
Printhead
Cleaning Interval
When Early Warning for Maintenance is enabled, set this value to the length of the
media or ribbon roll that you are using.
When the printhead reaches the set length, WARNING CLEAN PRINTHEAD appears on
the control panel display. If the alert function is enabled, the print engine generates an
alert.
Accepted values:
0 M/0 FT to 450M/1476 FT in 50 M increments
Related ZPL command(s):
^JH
SGD command used:
none
Control panel menu item: HEAD CLEANING on page 25
Printer web page:
View and Modify Printer Settings > General Setup
> Head Cleaning
Printhead Life
Expectancy
When Early Warning for Maintenance is enabled, set this value to the number of inches
of media that the printhead is expected to print.
When the printhead reaches the set length, WARNING REPLACE HEAD appears on the
control panel display. If the alert function is enabled, the print engine generates an alert.
Accepted values:
0 M/0 FT to 450M/1476 FT in 50 M increments
Related ZPL command(s):
^JH
SGD command used:
none
Control panel menu item: HEAD LIFE on page 25
Printer web page:
View and Modify Printer Settings > General Setup
> Head Life

Zebra ZE500 Specifications

General

Print technology	-
Maximum resolution	300 x 300 DPI
Maximum printing width	168 mm
Wi-Fi	No
Ethernet LAN	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Parallel ports quantity	1
Flash memory	64 MB
Internal memory	16 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 129-Auto, Code 39, Code 49, Code 93, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, MaxiCode, PDF417, POSTNET, QR Code, TLC39, UPC-A, UPC-E
Processor frequency	133 MHz
Page description languages	XML, ZPL, ZPL II
Display	LCD
Product color	Black
Housing material	Metal
Core diameter	25.4 mm
Ribbon length	600 m
Maximum label width	180 mm
Maximum media length	3810 mm
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 71 °C
Operating temperature (T-T)	32 - 104 °F
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 85 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	438 mm
Width	245 mm
Height	300 mm
Weight	17300 g
