Print Engine Orientation
The ZE500 print engines are available in a right-hand configuration (the print mechanism is on
the right) and a left-hand configuration (the print mechanism is on the left).
Figure 1 • Left-Hand (LH) Print Engine
Figure 2 • Right-Hand (RH) Print Engine
1
2 3
1
3
2
1
media door
2
control panel
3
power switch
