Zebra ZE500 User Manual

55
Printer Setup and Operation
Select a Data Communication Interface
8/23/12 P1051584-002
Select a Data Communication Interface
You may connect your print engine to a computer using one or more of the available
connections. The standard connections are shown in
Figure 8. A ZebraNet wired or wireless
print server option or a parallel port may also be present on your print engine.
Figure 8 • Communication Interfaces
Table 4 on page 56 provides basic information about data communication interfaces that you
can use to connect your print engine to a computer. You may send label formats to the print
engine through any data communication interface that is available. Select an interface that is
supported by both your print engine and your computer or your Local Area Network (LAN).
parallel port
USB port
wired Ethernet port
serial port
1
applicator port
1

Zebra ZE500 Specifications

General

Print technology	-
Maximum resolution	300 x 300 DPI
Maximum printing width	168 mm
Wi-Fi	No
Ethernet LAN	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Parallel ports quantity	1
Flash memory	64 MB
Internal memory	16 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 129-Auto, Code 39, Code 49, Code 93, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, MaxiCode, PDF417, POSTNET, QR Code, TLC39, UPC-A, UPC-E
Processor frequency	133 MHz
Page description languages	XML, ZPL, ZPL II
Display	LCD
Product color	Black
Housing material	Metal
Core diameter	25.4 mm
Ribbon length	600 m
Maximum label width	180 mm
Maximum media length	3810 mm
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 71 °C
Operating temperature (T-T)	32 - 104 °F
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 85 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	438 mm
Width	245 mm
Height	300 mm
Weight	17300 g
