59
Printer Setup and Operation
Connect the Print Engine to a Power Source
8/23/12 P1051584-002
Connect the Print Engine to a Power Source
The AC power cord must have a three-prong female connector on one end that plugs into the
mating AC power connector at the rear of the print engine. If a power cable was not included
with your print engine, refer to
Power Cord Specifications on page 60.
To connect the print engine to a power source, complete these steps:
1. Plug the female end of the A/C power cord into the A/C power connector on the back of
the print engine.
2. Plug the male end of the A/C power cord into an appropriate power outlet.
Caution • For personnel and equipment safety, always use an approved three-conductor
power cord specific to the region or country intended for installation. This cord must use an
IEC 320 female connector and the appropriate region-specific three-conductor grounded
plug configuration.
