Zebra ZE500 User Manual

Routine Maintenance
Clean the Printhead and Rollers
114
P1051584-002 8/23/12
4. Using Preventative Maintenance kit (part number 47362) or a solution of 90% isopropyl
alcohol and 10% deionized water on a cotton swab, wipe the print elements from end to
end. Allow the solvent to evaporate.
5. Use a lint-free cloth moistened with alcohol to clean the platen roller, pinch roller, and
peel roller. Rotate the rollers while cleaning.
6. Reload the ribbon and media (if used).
7. Close the media door.
1
Printhead elements (gray strip)
2
Cotton swab
3
Platen Roller
Note • If print quality does not improve after you perform this procedure, clean the printhead
with Save-a-Printhead cleaning film. Call your authorized Zebra distributor for more
information.
1 2
3

Zebra ZE500 Specifications

General

Print technology	-
Maximum resolution	300 x 300 DPI
Maximum printing width	168 mm
Wi-Fi	No
Ethernet LAN	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Parallel ports quantity	1
Flash memory	64 MB
Internal memory	16 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 129-Auto, Code 39, Code 49, Code 93, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, MaxiCode, PDF417, POSTNET, QR Code, TLC39, UPC-A, UPC-E
Processor frequency	133 MHz
Page description languages	XML, ZPL, ZPL II
Display	LCD
Product color	Black
Housing material	Metal
Core diameter	25.4 mm
Ribbon length	600 m
Maximum label width	180 mm
Maximum media length	3810 mm
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 71 °C
Operating temperature (T-T)	32 - 104 °F
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 85 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	438 mm
Width	245 mm
Height	300 mm
Weight	17300 g
