Zebra ZE500 User Manual

19
Introduction
Control Panel Display
8/23/12 P1051584-002
Exit Setup Mode
1. While in Setup Mode, press SETUP to exit the operating parameters.
The LCD displays SAVE CHANGES.
2. To return to the parameters, plus the LEFT ARROW.
OR
Press PLUS (+) or MINUS (-) to scroll through the exit options.
3. Press the RIGHT ARROW to select the displayed choice and exit Setup Mode.
When the configuration and calibration sequence finishes, the print engine returns to the Idle Display.
Table 2 • Navigation (Continued)
POWER PAUSE STATUS DATA
POWER PAUSE STATUS DATA
PERMANENT Stores values in the print engine even when power is turned off.
TEMPORARY Saves the changes until power is turned off.
CANCEL This option cancels all changes made since you entered Setup mode,
except for changes made to DARKNESS, TEAR OFF,
COMMUNICATION, and LANGUAGE settings, which go into effect as
soon as they are made.
LOAD DEFAULTS Use this option to restore all settings other than the network settings back
to the factory defaults. Use care when loading defaults because you will
need to reload all settings that you changed manually.
LOAD LAST SAVE Loads the values from the last permanent save.
DEFAULT NET Use this option to restore all print server and network settings back to the
factory defaults. Use care when loading defaults because you will need to
reload all settings that you changed manually.

Zebra ZE500 Specifications

General

Print technology	-
Maximum resolution	300 x 300 DPI
Maximum printing width	168 mm
Wi-Fi	No
Ethernet LAN	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Parallel ports quantity	1
Flash memory	64 MB
Internal memory	16 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 129-Auto, Code 39, Code 49, Code 93, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, MaxiCode, PDF417, POSTNET, QR Code, TLC39, UPC-A, UPC-E
Processor frequency	133 MHz
Page description languages	XML, ZPL, ZPL II
Display	LCD
Product color	Black
Housing material	Metal
Core diameter	25.4 mm
Ribbon length	600 m
Maximum label width	180 mm
Maximum media length	3810 mm
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 71 °C
Operating temperature (T-T)	32 - 104 °F
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 85 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	438 mm
Width	245 mm
Height	300 mm
Weight	17300 g
