Printer Setup and Operation
Handling the Print Engine
8/23/12 P1051584-002
2. Remove the metal spacer that ships next to the printhead-release latch. (Right-hand unit
shown.)
a. Cut the cable tie (1) that secured the printhead-release latch during shipping.
b. Rotate the printhead-release latch to expose the metal spacer.
1
