Device overview S88 / OPMI Lumera T
Version 8.0
Page 70 G-30-1682-en
8 Dust cover
9 Switch for unlocking the magnetic brakes of the suspension system
10 Clamp for asepsis caps
11 Handgrips for positioning the surgical microscope
With asepsis caps attached, the handgrips are used to position the
microscope and unlock the magnetic brakes.
12 Display of the magnification factor of the zoom system
13 Fastening screw for tubes or accessories
– Handgrip turned Magnetic brakes are unlocked, the device
can be moved as required.
– Handgrip not turned Magnetic brakes are locked, the device
cannot be moved.
