Device overview S88 / OPMI Lumera T
Version 8.0
Page 84 G-30-1682-en
Halogen light source (option)
The suspension system is equipped with a light source for fiber illumination.
The lamp housing contains a backup lamp which automatically swings into
position when the first lamp fails. If required, the light source can be equipped
with a second lamp housing so that two separate light sources are available
for fiber illumination.
1 Lamp module
2 Ventilation grid
3 Flap
The flap is used as the mechanical indicator for the operating status of the
halogen lamps.
– When the flap is closed, the main lamp is operative.
– When the flap is open, the main lamp has failed. The backup lamp is on.
4 Manual switching to the backup lamp
If the automatic activation function fails, press this button to switch on the
backup lamp.
5 Opening the lamp module
When you press this button, the slide-in lamp module is partially ejected.
Pull out the lamp module all the way for lamp change.
6 Filter selector
The filter selector knob has four positions:
NOTE Overheating of the lamp module!
If ventilation grids are covered e.g. by drapes, this may lead to overheating
of the ventilation modules and deactivation of the lamp.
• Never cover the ventilation grids.
• Lamps switched off due to overheating will be automatically switched on
again when they have cooled down.
no filter
blue barrier filter (retina protection filter): When operating on
the eye, always use this filter to protect the patient's eye against
unnecessary radiation (retinal injury).
KK 40 filter:
to increase the color temperature
