Device overview S88 / OPMI Lumera T
Version 8.0
Page 76 G-30-1682-en
Binocular tubes and eyepieces
You can mount a 180° tiltable tube, an Invertertube or a 45° inclined tube on
the Lumera T surgical microscope as required (see the following pages).
180° tiltable tube
1 Adjustment wheel for interpupillary distance
The correct position has been reached when the two eyepiece images
merge into one. You can read off the interpupillary distance set on the
adjustment knob.
2 180° tiltable tube
3 Eyepiece mounting
45° inclined tube
4 45° inclined tube
5 PD adjustment knob
The correct position has been reached when the two eyepiece images
merge into one. You can read off the interpupillary distance set on the
adjustment knob.
6 Eyepiece mounting
